Blizzard node:b RGBAL / Engine ONLY (Lens sold separately)
Blizzard node:b RGBAL / Engine ONLY (Lens sold separately)
Retail price
$559.99
Retail price
$799.99
Innovative LED Price
$559.99
Unit price
/
per
FREE Ground Shipping!
SKU:
2 in stock
Couldn't load pickup availability
BLIZZARD node:b RGBAL
Modular Architectural Lighting System
PLEASE NOTE: Lens sold separately!
Compact, Full Color Lighting System
The ETL-listed node:b™ RGBAL pairs a high-output 200W LED light engine with a variety of replaceable lens types to fit many applications ranging from gobo projection, to typical hard-edged profile use or even a smooth, vibrantly colored wash. This fixture is ideal for those in need of flexibility in their lighting.
Modular & Flexible Design
There are 3x lenses available for node:b™ fixtures with the choices of 15-30° or 25-50° profile zoom lenses with 4-blade manual shutters and focus, or a 16-65° Fresnel zoom lens. Lenses are sold separately.
User-selectable dimming curves, dimming speed, and frequency mode settings are also accessible from its 4-button OLED control menu.
Luminous Intensity
RGBAL Engine + 15-30° Profile Zoom Lens:
Lux/Meter 2.5 Meter 5 Meter
15° (narrow) 4,542 Lux 1,225 Lux
30° (wide) 1,549 Lux 397 Lux
RGBAL Engine + 25-50° Profile Zoom Lens:
Lux/Meter 2.5 Meter 5 Meter
25° (narrow) 1,813 Lux 427 Lux
50° (wide) 1,090 Lux 288 Lux
RGBAL Engine + 16-65° Fresnel Zoom Lens:
Lux/Meter 2.5 Meter 5 Meter
16° (narrow) 1,386 Lux 365 Lux
65° (wide) 576 Lux 148 Lux
Main Features
- Light source: 200W RGBAL COB LED
- Engine accommodates profile or fresnel lens barrels (sold separately)
- Small in size, 10cm fixture diameter
- Lens: glass optical lens
- 1-25Hz strobe effects
- Flicker-free resolution, perfect for video
- Adjustable LED refresh rates (1000-8000 Hz)
- 16-bit dimming, with 4 user-selectable dimming curves
- User selectable dimming speeds (low/medium/high)
- Dual mounting brackets for flexible positioning
- M12 sized bracket holes
- Heavy-duty, fixed power cord
- Quiet fan cooling
- 3-pin male/female XLR input & output connections
Optical
- 200W RGBAL LED
- Glass optical lens CRI: 90
- Flicker-free resolution
- Gobo holder: 68.6mm outer, 24mm inner, 0.4mm thickness
Weight & Dimensions
- 13.4” x 3.94” x 3.94” (34 x 10x 10 cm)
- 5.3 lbs. (2.4 kg)
Control
- Protocol: DMX, RDM
- 3-pin DMX in/out
- 6/9-channels
- 4-button menu with OLED display
- DMX512, master/slave, standalone
Power + Current
- 100-240VAC, 50-60 Hz
- Consumption: 156W 2.03A, PF: .95
- Heavy-duty, fixed power cord
Warranty + Certifications
2-year limited warranty
cETLus certified
