Blizzard Tournado ZOOM RGBAW (Black Housing)

MEET THE TOURNADO™ ZOOM RGBAW(Black Housing) LED PAR

Outdoor Rated R/G/B/A/W PAR with Zoom

It’s a way bright, way cool outdoor rated zoomable LED par can with all
of the exact same great features found in our classic ToughPar™ Zoom
RGBAW, only upgraded to our latest TOURnado™ housing design with
powerCON™ True1 compatible In/Out power connectors, and IP rated
3-pin In/Out connectors. Both the power and DMX connections found
on this fixture also have rubber sealing covers to protect them from
dust and water according to protection class IP65.

TOURnado™ Zoom RGBAW fixtures offer a fast & precise 10-40°
zoomable beam angle, outstanding color saturation and exceptional
pastel reproduction thanks to its 36x 3W LEDs (6 Red, 8 Green, 8 Blue,
6 Amber, and 8 White). Amber and white LEDs give the fixture the
ability to produce pastel colors not possible with conventional RGB LED
fixtures.

In DMX mode, you can control the fixture with either 5/7/9 or 11 DMX
channels. You’ll have full control of many features such as RGBAW color
mixing, beam zoom, strobe, ultra smooth flicker-free 32-bit dimming,
and 10 auto run modes. The 4-button LED control panel also allows total
control over the fixture including master/slave settings, 10 separate
customizable R/G/B/A/W based white balance settings, and more.

IP65 rated for outdoor use, the TOURnado™ Zoom RGBAW is built from
rock-solid cast aluminum with a tempered glass lens and watertight
internal gaskets. It’s ready to handle anything Mother Nature can send
its way!

And of course, they are also backed by Blizzard’s 2-year warranty!

Main Features

• 36x 3W R/G/B/A/W LEDs, 100,000 hours

• 10-40 degree zoomable beam angle

• Diffused Optical Lens

• Natural convection cooled, totally silent operation

• User selectable 32-bit dimming curves

• Variable electronic dimmer strobe

• Built-in color & chase macros via DMX

• Built-in auto programs in standalone and M/S

• Color mixing ability in standalone mode

•

• User selectable 5/7/9 or 11-channel DMX modes

• LED control panel with 4* touch sensitive buttons

• Control panel button lock/key

• 3-pin male input and 3-pin female output

• PowerCon™ True1 compatible AC power In/Out connectors

Power

• Voltage: 100-264VAC, 47-63 Hertz

• Power Consumption: 82W, 1.07A, PF: 62

Optical

• 36x 3W LEDs (R) 6PCS, G (8PCS), B (8PCS), A (6PCS), W (8PCS)

• 10-40 degree zoomable beam angle

• Illuminance (Wide) 8430 Lux @ 1 m, 2512 Lux @ 2 m

Illuminance (Narrow) 34200 Lux @ 1 m, 10900 Lux @ 2 m

Thermal

• Max. Operating Temp.: 104 degrees F (40 degrees C) ambient

Control

• Protocol: USITT DMX-512

• DMX Channels: 5/7/9 or 11-channels

• Input: 3-pin XLR Male

• Output: 3-pin XLR Female

• Standalone, Master/Slave, Color Preset

Weight & Dimensions

• Dimensions: 10.7” (272.1 mm) x 5.7” (144 mm) x 11.2 inches (284.1 mm)

• Weight: 11.5 lbs. (5.2 kg)

Warranty

• 2-year limited warranty, does not cover malfunction by damage to LEDs
