UVonix Blackstar
120W UV LED Blacklight Flood with Barndoors
True 365nm UV Light
UVonix™ Blackstar is designed to maximize UV output, while filtering out all non-365nm wavelengths. It features 12x 10W UV LEDs with ZWB2 longwave UV bandpass filters, a modern advancement on the Woods’ glass filter. ZWB2 filters permit 23% more UV light to pass while blocking unnecessary visible light, making luminescent objects & paints glow more vibrantly.
Packed with Features
Features include a 30° beam angle, adjustable LED refresh rates (900Hz - 25KHz), 4 dimming curves, flicker-free resolution, and a variety of strobe effects. It also offers light shaping capabilities with its 4-leaf barndoor attachment, flexible positioning with dual mounting brackets, 4-button control panel, 3/5-pin XLR in/out, and powerCON TRUE1-compatible in/out connections.
Main Features
• 12x 10W UV LEDs, 50,000+ hour lifetime
• UV-pass lens filters for pure 365nm wavelength
• 30° beam angle
• Electronic dimming & strobe effects
• Flicker-free resolution, perfect for video
• 4 user-selectable dimming curves
• 6 dimming delay settings (5/10/15/20/25/30ms)
• Adjustable LED refresh rates (900Hz-25KHz)
• Barndoor attachment for light shaping
• Dual mounting brackets for flexible positioning
• 3/5-pin male/female XLR input & output connections
• PowerCON TRUE1-compatible input/output connections
SpecsOverview
- 12x 10W UV LEDs
- 365nm UV-pass lens filters
- 900Hz-25KHz refresh rates
- 4 dimming curve settings
- 6 dimming delay settings
- Strobe effects
- Barndoor attachment
- Dual mounting brackets
Optical
12x 10WUV LEDs + UV pass lens filters
Wavelength: 365nm
30° beam angle
Flicker-free LEDs
Control
Protocol: USITT DMX-512
1/2/4-channel DMX
4-button control menu with LCD display
DMX-512, M/S, and standalone
3/5-pin DMX in/out
Power
100-240VAC, 50-60 Hz
Power consumption: 155W, 1.42A, PF: .99
Fuse: 3.15A 250V
PowerCON TRUE1-compatible input/output
Warranty
2-year limited warranty
Dims & Weight
12.8" L x 14.8" W x 9.4" H
20.7 lbs
